Details
| TV System | PAL | NTSC |
| Effective Pixel | P:1280(H)x 960(V) | N:1280(H)x 960(V) |
| Image Sensor | 1/3" CMOS Sensor 1000TVL | |
| Horizontal Definition | 1000TV Line | |
| Lens | 3.6 mm | |
| IR View Distance | up to 30 Meters | |
| LED | 4 High Power Array IR | |
| LED Switch | Auto | |
| Minimum Illumination | 0.01 Lux | |
| AGC | 0.25/0.50/0.75/1.00 adjustable | |
| Synchronization System | Internal | |
| Video Output | 1.0Vp-p75 ohm | |
| DNR | 2DNR | |
| OSD | Supported | |
| Scanning System | 2:1 Interlaced | |
| Backlight Compensation | High light compensation/common | |
| Electronic Shutter | 1/50(1/60)~1/100.000sec | |
| White Balance | Push/User/Anticr/Manual/Pushlock/ATW | |
| S/N Ratio | >55dB | |
| Gamma Correction | >0.45 | |
| Motion Detection | ON/OFF Selectable (Detect Area: 4) | |
| Privacy mask | ON/OFF Selectable ( Area: 4) | |
| ATR | Yes | |
| HLC | Yes | |
| AFD | Yes | |
| WDR | Yes | |
| Picture Adjust | Mirror/Brightness/Contrast/Sharpness/HUE/Gain | |
| Weather Proof Standard | IP66 | |
| Operation Temperature | -10~+55 | |
| Operation Humidity | 85%RH | |
| Power Supply | 12 VDC±10% | |
| Power Consumption | Max. 2A | |
