Details
System |
System |
Embedded Linux |
Video |
Codec |
H.264 |
Encode |
16*1080N@12fps |
|
Decode |
16*1080N@12fps |
|
Multi-mode |
Analog: 16*1080N@12fps; 8*1080N |
|
Hybird: 8*1080N@12fps(analog)+8*960P |
||
IP: 4*5M; 4*3M; 8*1080P+8*960P; 16*960P |
||
Playback |
16ch |
|
Audio |
Compression |
G.711a |
Intercom |
Support |
|
Management |
Record mode |
Manual>Alarm>Motion detection>Timing |
Inquire mode |
Inquire by Time/Calendar/Event/Channel |
|
Storage mode |
HDD Storage, Network Storage |
|
Backup |
Network, USB, SATA |
|
Interface |
Video input |
16*BNC(Support Coaxitron) |
HDMI output |
1*HDMI (MAX:1080P) |
|
VGA output |
1*VGA (MAX:1080P) |
|
Audio I/O |
2/1 |
|
Alarm I/O |
0/0 |
|
Ethernet port |
1*10/100Mbps Ethernet port, RJ45 port |
|
PTZ control |
1*RS485, Support for multiple PTZ protocol |
|
USB Port |
2*USB2.0 ports |
|
HDD |
1*SATA interface (Up to 6TB) |
|
General |
Temperature |
0 ℃ - + 55 ℃ |
Humidity |
10% -90% RH |
|
Power supply |
12V/2A |
|
Consumption |
<10W(Without HDD） |
|
Weight |
Around 1KG |
|
Dimension |
255(L)* 236mm(W)* 44mm(H) |
